KPM200 series communication management machine is an important part of the intelligent distribution automation system to complete the power distribution room microcomputer protection, automatic devices, monitoring and other intelligent devices and computer systems, power grid automation system to achieve the exchange of information between the far station information to the host Exchange and network exchange, thus forming a fully decentralized RTU communication system.
Function features
□Industrial grade Contex-A8 processor ，800MHz frequency
□512MB DDR3 SDRAM, 512Mflash
□Support 2/4-way high-speed 10 / 100M independent network interface
□Support 4/16-way RS485 serial communication interface
□Built-in real-time clock (RTC), temperature sensor and independent hardware encryption circuit to protect user IP
□Built-rich communication protocol library to support the electricity IEC60870-101 / 103/104 protocol, support ProfiNET, EtherNet, BACnet, SNPx and other communication protocols
□Built-in WEB server, support for remote development, configuration, commissioning and maintenance
□Achieve communication management, data gateway, data forwarding, protocol conversion, pre-processing and other functions
□CAN interface bidirectional optical isolation CAN2.0 interface standard
□Support all the way debug serial port, as well as WIFI wireless LAN / GPRS / 3G / 4G remote communications and other extensions
□Expandable 4-128G TF memory card
□Rugged metal shell and internal circuit "three defenses" treatment, especially for the harsh environment on site
